W6Mo5Cr4V2 Steel Single Helix Screw Element with Vacuum Hardening for Powder Coating Production

Product Description

One of the key features of this product is its connection method. The screw element is designed to be connected using a spline, which ensures a secure and reliable connection. This allows for smooth operation and consistent performance throughout the entire extrusion process.

Another important attribute of this product is its screw diameter. The screw diameter can be customized to fit specific requirements, ranging from 10mm to 300mm. This flexibility makes it an ideal choice for a wide range of applications and industries.

In terms of quality and reliability, this Single Rotating Screw Element is ISO9001 certified. This certification indicates that the product has undergone rigorous testing and meets the highest standards of quality and performance.

Features

•  Product Name: Single Flighted Screw Element
•  Treatment: Polishing/Sand Blast
•  Wear: High Wear-resistant
•  Screw diameter: 10mm-300mm (Can Be Customized)
•  Certificate: ISO9001
•  Tolerance: ±0.01mm

Technical Parameters

Product Name	Single Flighted Screw Element
Place of Origin	Sichuan China
Hardness	HRC 58-62
Tolerance	±0.01mm
Connection Method	Spline
Packaging	Paper Box Or Wooden Box
Standard	DIN, GB, Etc.
Service Provided	Video Technical Support
Corrosion	Corrosion Resistance
Heat Treatment	Vacuum Hardened
Material	W6Mo5Cr4V2

Applications

Our Single Rotating Screw Element is perfect for industries that require precision and reliability. It has a tolerance of ±0.01mm, making it a great choice for applications that require accuracy. The screw diameter can be customized from 10mm to 300mm, ensuring that you get the right size for your specific needs.

The Single Spiral Screw Element is versatile and can be used in many different applications. Our product meets all DIN, GB, and other relevant standards, ensuring that it is compatible with a wide range of machines and industries. It is also corrosion-resistant, making it a great choice for applications that require durability and longevity.

Our product can be used in a variety of occasions and scenarios, including but not limited to:

•  Manufacturing plants
•  Food processing plants
•  Chemical plants
•  Paper mills
•  Wastewater treatment plants

We offer competitive pricing and a minimum order quantity that is negotiable. Our products are shipped in wooden packaging, ensuring that they arrive safely and intact. Our delivery time is 30-60 days, and we have a supply ability of 300M/month, ensuring that we can meet your needs in a timely manner.

Overall, our Nanxiang Machinery Single Flighted Screw Element is a high-quality product that is perfect for a wide range of applications. It is a reliable and durable choice that meets all relevant standards and certifications. Contact us today to learn more about how our product can meet your specific needs.

Production Process

	NO.1   Workblank     Select high-quality raw materials
NO.2   Piecewise According to the drawing section length
	NO.3   Hit bottom hole Rough machining the bottom hole,and then pull spline
NO.4   Machining thread Professional high-end processing equipment,rough machining threads
	NO.5   Finish machining thread
NO.6   Threading grinding Further control of tolerance Length:-0.01mm-+0.01mm OD:-0.03mm-0mm Transition arc:-0.02mm-+0.02mm

Our Service

Product accuracy

There are some differences between Nanxiang Machinery and Nanjing's production technology. Their finishing process is carried out before heat treatment, and the deformation after heat treatment is not controlled, so their accuracy is not easy to control. But our finishing process is carried out after heat treatment, which can eliminate the deformation of parts in heat treatment, so the precision is higher, and thus can achieve zero seam connection.

Packing&Delivery

Packing Details: According to your order quantity packaging, shipping wooden boxes, air carton.

Delivery Details: 20-60days after order.

Packing

According to your order quantities and products sizes to choose wooden boxes or cartons to pack:

a. Rust-proof oil processing,

b. Oiled paper packages,

c. Bubble wrap package,

d. Special foam packaging,

e. Packing,

f. Sealing.

Customer Trust

Certificate

Why choose us?

Nanxiang Machinery is a specialized manufacturer of precision-machined components for twin-screw extruders, including threaded elements, kneading blocks, mandrels, super-hard screw accessories, and wear-resistant alloy steel sleeves. Our products are widely applied in renowned international brands such as Coperion, Lerstritz, Berstorff, KOBE, and JSW, serving industries like plastics, food, feed, pellet manufacturing, pharmaceuticals, and new energy.

FAQ

Q: Are these screw elements resistant to high temperatures?
A: Yes, W6Mo5Cr4V2 steel maintains excellent hardness and structural stability at elevated temperatures, making it highly suitable for high-heat applications.

Q: What sizes and dimensions are available?
A: Our screw elements are available in diameters ranging from 7.8mm to 500mm, with customizable flight depth, lead angle, and helix geometry based on client requirements.

Q: Do you offer OEM or custom-designed screw elements?
A: Yes, we provide OEM and fully customized solutions to match specific extruder brands and processing requirements.
