Product Description

Our Side Feeder Elements come with video technical support, providing you with the necessary assistance for installation and maintenance. Our team of experts is always ready to help you with any queries or issues you may have.

The screw diameter of our Side Feeder Elements can be customized according to your specific requirements, ranging from 10mm to 300mm. This allows you to choose the perfect size for your extrusion process, ensuring precision and accuracy in your outputs.

The hardness of our Side Feeder Elements is HRC 58-62, ensuring a high level of strength and durability. Additionally, our Side Feeder Elements undergo vacuum hardening during heat treatment, further enhancing their durability and wear resistance.

Our Side Feeder Segmented Elements are designed to provide precise and consistent feeding of materials into the extruder, ensuring a high level of accuracy in your outputs. Our Side Feeder Compounding Elements are ideal for compounding and mixing applications, providing an efficient and reliable solution for your needs. Our Side Feeder Metering Elements are designed to provide accurate metering of materials, ensuring precise control and consistency in your outputs.

Technical Parameters:

Product Name	Side Feeder Elements
Screw Design	Single flighted
Hardness	58-60HRC
Brand Name	Nanxiang Machinery
Surface Treatment	Polishing/Sand Blasting
Supplier	Factory Direct
Place of Origin	Sichuan , China
Warranty	6 months
Application	Extrusion Machine
Suit For	Pharmaceuticals Extrusion Chemical Extrusion Food Extrusion Powder Coating Extrusion

Reasons for Utilization

1. Substantial reduction of wear costs in the melting section of the main screw and barrels
2. Gentler and more delicate processing of fillers
3. Considerable increase in throughput
4. Significant increase in quality through adequate and sufficient fixing
5. Substantial lowering of the cost

Applications

The Side Feeder Metering Elements are suitable for use in a range of different product application occasions and scenarios. For example, they can be used in the production of automotive parts, electrical components, packaging materials, and more. They are also suitable for use in the production of consumer goods, such as toys and household appliances.

The Side Feeder Metering Elements are manufactured to the highest standards, and are certified to ISO 9001. They are available in a range of different models and can be customized to meet the specific needs of individual customers. Minimum order quantities are negotiable, and prices are also negotiable depending on the order size.

The Side Feeder Metering Elements are highly corrosion-resistant, ensuring long-lasting performance even in harsh environments. They are also highly wear-resistant, making them suitable for use in demanding applications. The elements are manufactured to meet a range of different standards, including DIN and GB.

Support twin-screw extruder brand

Production Process

	NO.1   Workblank     Select high-quality raw materials
NO.2   Piecewise According to the drawing section length
	NO.3   Hit bottom hole Rough machining the bottom hole,and then pull spline
NO.4   Machining thread Professional high-end processing equipment,rough machining threads
	NO.5   Finish machining thread
NO.6   Threading grinding Further control of tolerance Length:-0.01mm-+0.01mm OD:-0.03mm-0mm Transition arc:-0.02mm-+0.02mm

Our Service

Product accuracy

There are some differences between Nanxiang Machinery and Nanjing's production technology. Their finishing process is carried out before heat treatment, and the deformation after heat treatment is not controlled, so their accuracy is not easy to control. But our finishing process is carried out after heat treatment, which can eliminate the deformation of parts in heat treatment, so the precision is higher, and thus can achieve zero seam connection.

Packing&Delivery

Packing Details: According to your order quantity packaging, shipping wooden boxes, air carton.

Delivery Details: 20-60days after order.

Packing

According to your order quantities and products sizes to choose wooden boxes or cartons to pack:

a. Rust-proof oil processing,

b. Oiled paper packages,

c. Bubble wrap package,

d. Special foam packaging,

e. Packing,

f. Sealing.

Customer Trust

Certificate

Why choose us?

Nanxiang Machinery is a specialized manufacturer of precision-machined components for twin-screw extruders, including threaded elements, kneading blocks, mandrels, super-hard screw accessories, and wear-resistant alloy steel sleeves. Our products are widely applied in renowned international brands such as Coperion, Lerstritz, Berstorff, KOBE, and JSW, serving industries like plastics, food, feed, pellet manufacturing, pharmaceuticals, and new energy.
